Industrial Poultry Feed Plants & Pelleting Systems
Adhering to international biosecurity standards, we design and deliver high-performance commercial poultry feed mills built for optimal FCR, structural safety, and high-volume throughput.
Precision Bio-Engineering
Maximize FCR & Profitability with Advanced Process Architecture
Commercial poultry feed manufacturing demands an exact balance between biological safety and process economics. Our engineered poultry feed plants are meticulously configured from raw material intake to bulk loadout to deliver uniform, highly digestible, and pathogen-free feeds.
Through optimal steam-conditioning parameters, precise micro-component batching, and highly efficient grinding matrices, Milling Equips plants enable integrators and commercial millers to achieve superior Feed Conversion Ratios (FCR), minimize raw ingredient dust, and extend pellet mill die life.
Double-pass steam conditioning
Pathogen & Salmonella elimination
Dynamic micro-ingredient dosing
Low fines generation (<5% at bagger)
Fig A. Premium Poultry FeedMilling Equips EPC
Technical Mastery
Engineered Performance Specifications
Milling Equips constructs all systems to meet global manufacturing parameters. Our engineering values represent industry benchmarks for reliability and energy conservation.
Technical Parameter Matrix
Plant Capacity Range
5 to 60 Tons Per Hour (t/h)
Pellet Size Configurations
1.8 mm to 8.0 mm (Broiler Starter, Grower, Finisher & Layers)
Conditioning Technology
Double-Pass Jacketed Steam Conditioners, 304 Stainless Steel
Conditioning Retention Time
60 to 120 Seconds
Biosecurity Sterilization Temp
82°C to 90°C (100% Salmonella and Pathogen elimination)
Control System
Siemens S7-1500 PLC with SCADA Real-Time Automation & Dosing Accuracy
Transmission Drive Options
High-torque Gear Drive or Heavy-Duty V-Belt Transmission
Dosing Weighing Precision
Dynamic weighing accuracy up to ±0.1% for micro-ingredients
Biosecurity Core
Integrated high-temperature conditioning system guarantees complete pathogen load reduction, protecting livestock health and ensuring compliance with national export regulations.
Optimized FCR
Precision grain particle size distribution and steam-induced starch pre-gelatinization result in a cohesive, highly nutritional pellet that optimizes feed consumption and assimilation.
EPC Contracting
From soil excavation, structural steel frame fabrication (AISC Standards) to mechanical, automation, and trial runs, we offer complete peace of mind with unified responsibility.
Modular Workflow
State-of-the-Art Processing Modules
Our integrated poultry feed plants utilize modular engineering to ensure uninterrupted product flow, minimal maintenance, and energy savings of up to 25%.
01
Precision Batching
High-accuracy micro-dosing systems for vitamins and amino acids integrated with automatic bulk batching scales to secure strict formulation compliance.
02
Homogenous Mixing
Twin-shaft paddle mixers blend dry micro-ingredients, grains, and added fats/oils to a Coefficient of Variation (CV) < 5% in under 90 seconds.
03
Thermal Conditioning
Jacketed double-pass conditioners cook the mash using dry saturated steam, increasing starch gelatinization and destroying salmonella cells.
04
Die Extrusion & Cooling
Heavy-duty ring die pellet mills compress the hot mash into durable pellets, followed by counter-flow cooling to stabilize moisture to 12.5%.
Consultation & Custom Layout Design
Ready to Establish a Highly Biosecure Poultry Feed Plant?
Partner with Milling Equips. Share your target capacity, area coordinates, and animal profiles, and our senior process engineers will draft a detailed layout and feasibility report.
✓ Complete turnkey EPC✓ Low maintenance warranty✓ High energy efficiency
Continue Exploring
Explore Other Feed Milling Solutions
Beyond poultry feed, Milling Equips engineers industrial-grade feed mills for cattle and aquaculture.
